| Place of Origin | CHINA |
| Brand Name | XCMG |
| Certification | ISO9001 |
| Model Number | XSC3311 |
1.Optimal matching of chassis.
XCMG concrete machine mixer XSC3311 equipped with SINOTRUK industry-leading dual power control technology is adopted to carry out the real-time control and adjustment for different drum load, effectively reducing fuel consumption of products.The adoption of classical golden power transmission chain provides more durable products, more convenient maintenance and lower cost.
2.Comprehensive improvement of key parts' reliability.
XCMG concrete machine mixer XSC3311 adopts hydraulic parts of famous brands and transmission shaft of long service life improves the system’s reliability by once.Feed hopper and chute are made of multilayer high-strength wear-resistant liner plate, with the service life increased by 50%.
3.Efficient mixing technology.
Low dip angle is designed, with the angle 5% lower than that of XCMG concrete machine mixer XSC3311's counterparts and the stability improved by 18% under equivalent loading capacity.
Product Parameter
| CATEGORY | ITEM | UNIT | XSC3311 |
| Performance of mixing drum | Rev. | r/min | 0~14 |
| Charging speed | m³/min | ≥3 | |
| Discharging speed | m³/min | ≥2 | |
| Residual ratio of discharging | % | ＜0.4% | |
| Hydraulic system | Oil pump | World-famous brand | |
| Motor | World-famous brand | ||
| Speed reducer | World-famous brand | ||
| Water supply | Volume of water tank | L | 450 |
| Overall vehicle | Chassis model | ZZ1257N4347E1 | |
| Curb mass | Kg | 16170 | |
| Drive type | 6×4 | ||
| Wheel base | mm | 4325+1350 | |
| Tire | 12.00R20 | ||
| PTO way | |||
| Outline dimensions | mm | 10470×2500×3995 | |
| Engine | Model | D10.34-50 | |
| Rated power | kW | 249 | |
| Fuel | Diesel | ||
| Emission standard | China V |
