Girder

Vertical Plate 8 mm

Upper wing plate 10 mm

Lower wing plate 12 mm

Model quantity

13TTie niu axle *4 pcs

Girder style

Straight beam

Tire

Triangle1200R22.5/16sets

Side beam

140# square tube

Toolbox

1 standard

Through beam

High-strength bending parts

Hydraulic cylinder

200#

Air chambers

6sets

Edge style/thickness

Flat plate 4.0 mm

Bottom Plate Form/Thickness

Flat plate 3.0 mm

Landing gear

single action28T

Suspension

Mechanical suspension

Traction pin model

About 3.5 inchs

Tractor saddle height

1300mm

Brake Valve Specifications

Three-axle synchronous

Overall size; 9.2meters long X 2.5 meters wide X 1.8 meters high.

Internal dimensions: 8.5m long X 2.3m wide X 1.8m high, volume: 35 cubic meters.
