| Place of Origin | CHINA |
| Brand Name | SDLG |
| Certification | ISO9001 |
| Model Number | RS8180h |
SDLG Lingong Compactor 18tons 20tons RS8180h RS8200h Road Roller
Product Advantages
Equipped with a WP6G160E201 turbocharged water-cooled engine and a mechanical high-pressure fuel pump, meeting Tier II emission standards. The engine delivers a power output of 118 kW, a maximum speed of 2000 rpm, and a maximum torque of 600 N·m.
An additional throttle control lever (manual throttle) is mounted on the selector.
A seal is installed around the radiator perimeter for more efficient heat dissipation by separating the hot and cold zones of the engine compartment. The radiator is equipped with a sight glass for checking the coolant level.
| Operating weight | 18000 |
| Rated power (kW) | 118 |
| Compaction width (mm) | 2150 |
| Overall dimension (L×W×H)(mm) | 6295x2300x3170 |
| Engine model | WP6G160E201 |
| Nominal amplitude (mm) | 2.0/1.0 |
| Excitation force (kN) | 420/295 |
| Steering angle (°) | 35 |
| Min. turing radius (mm) | 6389 |
| Fuel tank capacity(L) | 270 |
