| Place of Origin | CHINA |
| Brand Name | FAW |
| Certification | ISO9001 |
| Model Number | CA4250P66K24T1A1E5 |
Product Parameter
| Truck model | CA4322P2K15T1YA80 | ||
| Manufacturing Company | FAW | ||
| Drive wheel | 6x4 | ||
| Engine | Model | WD615.38 | |
| Manufacturing Company | WEICHAI POWER | ||
| Maximum output | 380HP | ||
| Emission standard | Euro II | ||
| Number of cylinder | 6-cylinder in-line with water cooling, turbo-charging and intercooling | ||
| Transmission | CA9TB160M | ||
| Clutch | Import USA EATON, 430mm | ||
| WABCO valve, WABCO clutch booster, maintenance-free battery | |||
| Front Axle | A1H | ||
| Rear Axle | 457 (rate:4.111) | ||
| Chassis | Frame | 300*80*8mm | |
| Fuel tank | 380L | ||
| Steering | TRW tech | ||
| Brakes | Drum | ||
| Wheel Base(mm) | 3300+1350 | ||
| Wheels&Tires | Tire: 315/80R22.5 tubeless | ||
| Driver Cabin | J5P,1 sleeper, A/C, Electric lifting, All-steel bumper | ||
| Electrics | Operating voltage | 24v | |
| Starter, Alternator | China brand | ||
| Overall Dimensions | Overall Length | 6793mm | |
| Overall Width | 2496mm | ||
| Overall Heigth | 2980mm | ||
| Performance | Maximum speed | 88 km/h | |
