Dump Truck
>
|
|
| Place of Origin | CHINA |
| Brand Name | FAW |
| Certification | ISO9001 |
| Model Number | SSF3042DDP53-1 |
1. Strong power,China famous brand engine-Weichai or FAW Engine
2. Comfortable driving: One&half rows sleep cabin, with air conditioning(cooling&heating), power steering
3. Thicken and heighten cargo body,large capacity and more durable
4. Safety: ABS, air brake
Product Parameter
| Description | FC1800 1.5 Cabin Dump Truck | |
| Item | FENG CHI 1800 | |
| Model | SSF3042DDP53-1 | |
| Cabin | ONE AND HALF ROWS CABIN | |
|
whole
|
Overall dimensions (L*W*H)mm | 5680×2030×2440 |
| Dimensions of cargo body (L*W*H)mm | 3400×1870×(490+200) | |
| Driving type | 4×2 | |
| Wheel base | 3000 | |
| Wheel track(F/R)mm | 1170/1510 | |
| Min ground clearance (mm) | 190 | |
| Weight data |
Curb weight (kg) | 3020 |
| Rated payload(kg) | 4000 | |
| Person in cab (persons) | 3 | |
| whole vehicle main performance |
Max.speed(km/h) | 90 |
| Max.slope of climb(%) | 25 | |
| Min.turning radius (m) | 7.5 | |
| Engine | Engine model | 4DW93-84E5 |
| Engine type | Vertical, water-cooled, four-stroke, turbocharged and inter cooled |
|
| Fuel injection equipment | Common-rail with EDC+DPF | |
| Emission standard | Euro5 | |
| Displacement (L) | 2.54 | |
| Rated power (KW) | 64 | |
| Max torque (N.m/rpm) | 220N.M/ 1900-2100 r/min | |
| Steering gear type | Power steering | |
| Brake system | Service brake and boosting type | Air brake |
| Parking brake | Central drum brake | |
| Auxiliary brake | Air brake | |
| Wheels and tyre size | 7.50-16/7.50-16 | |
| Electric system | Rated voltage | 24V |
| Battery | 100Ah | |
