| Place of Origin | CHINA |
| Brand Name | SHACMAN |
| Certification | ISO9001 |
| Model Number | SX3315DU366 |
We are one of the best export company in China,We supply all kinds of trucks and constructiuon machinery, We are professional do this for about 10 years!
Please be assured that we are able to provide you with the best products and the best qualityservice!
Product Parameter
| Max. speed(km/h) | 77 | ||
| Drive System | 6×4 | ||
| Curb weight(kg) | 12100 | ||
| Total mass(kg) | 25000 | ||
| Dimensions (L*W*H)(mm) | Overall | 8329*2490*3450 | |
| Dumper | 5600*2300*1500 | ||
| Thickness | Floor 8, side 6 | ||
| Hydraulic system | HYVA 172 front lifting | ||
| Wheel base (mm) | 3800 + 1350 | ||
| Wheel track (mm) (F/R) | 1939 / 1860 | ||
| Overhang (mm) (F/R) | 1525 / 1654 | ||
| App./ Dep. Angle | 28 / 30 | ||
| Engine | WD12.336 (WEICHAI ,Euro 2 ) | ||
| Rated horsepower | 336 hp | ||
| Gearbox | RTD-11509C (FAST GEAR ) | ||
| Steering | ZF technology | ||
| Cab | MAN F2000 mid-lengthened flat roof cabin with A/C & sleeper F2000 |
||
| Axle | Front | 7.5 Ton | |
| Rear | 2*13Ton hub reduction axle , final ratio 5.73 | ||
| Tire | 11.00R20 | ||
| Fuel tanker (L) | 380 | ||
Detailed Photos
