| Place of Origin | CHINA |
| Brand Name | SHACMAN |
| Certification | ISO9001 |
| Model Number | SX3315DU366 |
We are one of the best export company in China,We supply all kinds of trucks and constructiuon machinery, We are professional do this for about 10 years!
Please be assured that we are able to provide you with the best products and the best qualityservice!
Product Parameter
| Drive System | 6×4 |
Cab |
F2000 Cabin with one sleeper |
Overall Dimension (mm) |
8329*2490*3450 |
Box Dimension (mm) |
5600*2300*1500 19.32CBM |
Box Steel Thickness (mm) |
Bottom 8mm, Side 6mm |
Loading capacity |
35 Tons |
Lifting |
Middle Lifting / Front Lifting |
Engine |
WP10.340E32 ( WEICHAI, Euro 2 ) |
Rated power |
340 hp |
Transmission |
9JS135 |
Clutch |
430 Diaphragm type |
Steering |
ZF technology |
Wheel base (mm) |
3800+1350 |
Front Axle |
7.5T MAN |
Rear Axle |
13 Ton STR axle, double reduction. |
Approach / depature angle (° ) |
20 / 20 |
Overhang (mm) (F/R) |
1525 / 1654 |
Track width (mm) (F/R) |
1939 / 1860 |
Tire |
Bias tire 11.00-20 |
Fuel Tank |
380L |
Detailed Photos
