| Place of Origin | CHINA |
| Brand Name | SDHIM |
| Certification | ISO9001 |
| Model Number | SDHIM |
Product Description
| Dimension | 13000mm*2500mm*4000mm |
| Load Capacity(T) | 40T |
| Axle | 2 axles |
| Tire | 8 units |
| Suspension | Mechanical suspension |
| King pin | brand 2.0 or 3.5inch(bolted or welded type) |
| Support leg | brand |
| Main beam | Height: 500mm Upper Plate: 14mm Middle Plate: 8mm
Bottom Plate is 16mm; Material: Q345B Steel |
| Side beam | 16mm or 18mm steel channel(Material: Q235steel) |
| Brake chamber | WABCO |
| ABS | Optional |
| Valve | WABCO valve |
| Light | LED light (specially intended for oversea market) |
| Voltage | 24V |
| Receptacle | 7-pin Socket (for 7 wire harness) |
| Semi Trailer
Surface Coating |
Sandblasted, anti-rust chassis surface is available with 1layer of anticorrosive primer and 2 layers of top coats |
