| Place of Origin | CHINA |
| Brand Name | SDHIM |
| Certification | ISO9001 |
| Model Number | HH30Z-W1-D |
3 Ton Diesel Telescopic Forklift With Japanese ISUZU Engine
product Parameter
| Generals | Model | Unit | HH30 | HH30Z | |
| Power type | Diesel | ||||
| Rated capacity | Kg | 3000 | |||
| Load center | mm | 500 | |||
| Dimensions | Lift height | mm | 3000 | ||
| Free lift height | mm | 130 | |||
| Fork size (L×W×T) | mm | 1070×125×45 | |||
| Mast inclination F/R | Deg | 6°/12° | |||
| Fnt overhang | mm | 490 | |||
| Overall Dimensions | Length to face of fork | mm | 2680 | ||
| Overall width | mm | 1225 | |||
| Mast lowered height | mm | 2095 | |||
| Overhead guard height | mm | 2120 | |||
| Turning radius | mm | 2460 | |||
| Min. right angle aisle width | mm | 2105 | |||
| Performance | Travel speed | Unload I/II | Km/h | 9/20 | |
| Full load I/II | Km/h | 8.8/18.5 | |||
| Lift speed | mm/s | 480 | |||
| Max. grade ability | % | 20 | |||
| Max. drawbar pull | Kn | 13 | |||
| Self weight | Kg | 4400 | |||
| Wheels & Tires | Tires | Front | 28×9-15-12PR | ||
| Rear | 6.50-10-10PR | ||||
| Tread | Front Q | mm | 1000 | ||
| Rear S | mm | 970 | |||
| Wheelbase | mm | 1700 | |||
|
Min. ground clearance (unload/full load) |
Mast | mm | 152/132 | ||
| Frame | mm | 158/138 | |||
| Drive units & Control | Battery | V/Ah | 12/90 | ||
| Engine | Model | C240 | |||
| Rated output | Kw/rpm | 34.5/2500 | |||
| Rated torque | N.m/rpm | 139/1800 | |||
| Displacement | cc | 2369 | |||
| Transmission | Type | Hydraulic | |||
| Shift Fwd/Rwd | 1/1 Power shift | ||||
| Operating pressure | Mpa | 17.5 | |||
