| Place of Origin | CHINA |
| Brand Name | SINOTRUK |
| Certification | ISO9001 |
| Model Number | ZZ3257N3847A |
1. Chassis with the design conception of modularization, to enhance the generic rare of the spare parts in different models, reduce the varieties of spare parts, facilitate to store after sales spare parts
2. Airbag shock seat can ne optional, cabin with the suspended floating design, can effectively reduce the bumping of the road and improve the comfortability.
3. braking system:
Key valve components all adopt the commercial vehicle electronic brake system produced by WABCO company, the technical requirements completely meet European standard, braking performance is excellent, to ensure driving safety.
Product Parameter
| Model | ZZ3257N3847A |
| Overall dimension(mm) | 8600*2600*3500mm |
| Box Size | 5600x2300x1600(mm),floor 8mm,side 6mm |
| Loading capacity | 20-30Ton |
| Horse Power | 380HP |
| Type | 6-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled, direct injection |
| Cab | HW76 one berth,safety belt,two seats,with A/C |
| Gear Box | HW19710, 10forward & 2reverse |
| Steering | ZF8118 hydraulic assistence |
| Front Axle | HF9 axle. Capacity: 9000k |
| Rear axle | HC16 axle. Capacity:2x16000kg |
| Tyre | 12.00R24, 11units(one spare tyre) ,Radial tyre |
| Wheelbase | 3600+1325mm |
| Parking brake | spring energy, compressed air operating on rear wheels |
| Auxiliary brake | Engine exhaust brake |
| Brake system | Air brake with WABCO value Fuel tank:300L |
| Fuel types | Diesel |
| Max speed | 75km/h |
| Lifting system | Ventral lifting by hydraulic pump cylinder |
| Other configuration | English dashboard, with air conditioner , with spare tyre, with bumpe |
| Origin of Goods | China |
